Foils, Films, Fibreglass Polyimide (reinforced)
ICT-BR
Thermally Conductive Sheet ICT-BR
Fact Sheet
The BR type is the latest development in highly thermally conductive, electrically insulating film types. This new high-performance product has outstanding long-term stability and offers excellent thermal, mechanical and electrical properties. The material is also very well balanced in terms of cost performance and offers an optimal alternative to other competitor materials in the field of highly thermally conductive, glass fiber reinforced silicone films.ICT-BR is also available on rolls and with adhesive on one side.
ICT-BR is therefore used in many areas of power electronics due to its durability and associated high reliability. This product was developed by the manufacturer for use in so-called power tool applications and for automotive applications such as air conditioning compressors, PTZ interior heaters, etc.
ICT-BR is therefore used in many areas of power electronics due to its durability and associated high reliability. This product was developed by the manufacturer for use in so-called power tool applications and for automotive applications such as air conditioning compressors, PTZ interior heaters, etc.
Product properties for ICT-BR(*)
| Property | Value | Test Method |
|---|---|---|
| Thermal Properties | ||
| Operating temperature | from -60 to 180 °C | OEM/ICT |
| Thermally conductive | Yes | OEM/ICT |
| Thermal conductivity | 4 W/m*K | ASTM D 5470 |
| Thermal resistance (TO-3P / ca. 360mm²) | 0.21 °C/W | OEM/ICT |
| General Properties | ||
| Density | 2.1 g/cm³ | ASTM D 792 |
| Flammability (UL 94) | 94 | UL 94 |
| Color | White | Visual |
| Material | Silicone with glass fiber Aufbau | OEM/ICT |
| Electrical Properties | ||
| Dielectric strength | 2.0 kV (AC) | OEM/ICT |
| Electrically conductive | No | OEM/ICT |
Variants (*)
| Specification | Thickness (mm) | K/W/Inch |
|---|---|---|
| ICT-BR20 | 0.18 | 0.210 |
| ICT-BR30 | 0.28 |
* Subject to change and errors excepted.
